| TouchPLC TM |
| Free Flow Ladder on Screen |
» Super Enhanced HMI
» 32 DI/O, 6 AI/O, Expandable to 128
» 2.2ms Scan Time
» 2 100Khz Encoder Channels
» 4 PLS Outputd, 40µsec response time
» 3 PWM Outputs
» Free Flow Ladder Logic
» Monitor/Force Logic on Screen
» Gateway to other Networks, DH+, Ethernet, etc.. |
|
 |
| TouchPLSTM..on Ethernet |
| Super Fast, Accurate & Integrated |
» Touchscreen Graphical PLS setting
» 4096 bit/rev, 0.1°, 30 µsec Scan
» -67°F-248°F, NEMA 4, Expl. Proof, Resolver
» Ratio Converter for Resolver 2500ft away
» Leading/Trailing Edge Speed Compen.
» Flash Module for User Programs
» Built-in Productivity Monitor
» Can even be the OI for PLC
|
|
 |
| PowerTextTM |
| High End Features in a Low Budget Package |
» Data Read from any register
» 3 variables per line
» User defined Tricolor enunciators
» Save cost of other panel lights
» Folder organized messages
» Easy-to-use, navigate & program
» 3 yr Warranty
» Customizable/Field insert legends
|
|
 |
| G2 & Q2 PowerPanelTM |
| SCADA Like, without the "PC" Pain |
» Easiset to use bullet proof software, Free!!
» Flash for user program and firmware
» Alarm History, Recipes, Trends & Export to excel
» Dual drivers with connectivity to most PLCs
» NEMA 4X, Class I Div 2, UL, CE, Stainless Steel
» 32bit floating point math, scroll list, expressions SPC, CPK and down time monitoring built-in
» Full Data Acquisition package built-in
» Vector based graphics and incredible touch response
» Unique online programming saves MEGA $$$
» Plug & Play replacements for AB, TCP and other Obsolete panels with free program conversion
|
|
 |
| Smart PowerMarqueeTM |
| Eliminates PLC Programming, also has its own PLC |
» Easiset to program ... in minutes
» Up to 1MB memory for messages
» Built-in tag/alarm monitoring
» Built-in Data acquisition & trending
» Dual drivers & connectivity to most PLCs
» Gateway to other PLCs, DH+, Ethernet, etc.
» Matched LEDs with 4yr Warranty
» Optional built-in 32 I/O PLC for totally independent operation
» Variety of sizes, small, big and ver big!
» Stainless Steel option
|
|
 |
| PowerIPCTM |
| Hinged Bezel for Low MTTF |
» Mean time to fix < 2 mins
» Dual VGA Outputs
» Noise, NEMA 4X & electrical ratings
» Pre configured & ready to run
» Guranteed stable 3 yr supply
» CPU temp & fan speed motors
» Full Data Acquisition package built-in
» Stainless Steel option
» 2 yr Warranty
» Analog intensity adjustment
|
|
 |
|
|
 |
|
